2014 Raymond 750‑DR32TT | Deep Reach Truck | 3,000 lb | 114/252" TSU Mast | 36V Electric | Side‑Shift | CSA Certified | Brampton ON
Specifications
| Manufacturer | Raymond |
| Model | 750-DR32TT |
| Year | 2014 |
| Condition | Refurbished |
| Part ID | 5951630 |
| Capacity | 3200 lbs |
| Fuel Type | Electric |
| Raised Mast Height | 252 in |
| Lowered Mast Height | 114 in |
| Mast Type | Triple‑Stage (TSU) |
| Voltage | 36V |
| * Side Shifter | Yes |
| * Fork Length | 42" |
| Hydraulic Controls | 4‑Way |
| Hours | 17,934 drive / 1,885 lift |
| Battery Included | Optional |
| Charger Included | Optional |
| Certification | CSA/MOL Certified |
| Tire Type | Cushion, Non‑Marking |
| Base leg opening | ID/OD: 43" / 52" |
| Battery Box Dimensions | 38" x 21" x 32" |
| Category Overview Title | Deep Reach Forklifts – High‑Density Narrow Aisle Solutions |
| Category Overview Summary | Deep reach forklifts are engineered for high‑density racking, narrow aisles, and double‑deep pallet storage. With extended reach mechanisms, stable chassis design, and precise hydraulic control, they maximize warehouse capacity while reducing travel time. All Premier units are CSA/MOL certified, fully reconditioned, and available with battery/charger packages. |
Description
This 2014 Raymond 750‑DR32TT is a high‑performance deep‑reach forklift engineered for double‑deep pallet storage, narrow‑aisle warehousing, and high‑density distribution environments. With a 3,000 lb capacity, a 114/252" triple‑stage mast, and a 36‑volt electric system, this unit delivers exceptional lift height, reach stability, and operator visibility.
This forklift has been fully reconditioned by Premier Lift Equipment, including mechanical overhaul, paint restoration, safety decals, and full CSA/MOL certification.
Battery and charger packages are available in lead‑acid or lithium.
Ships from Brampton, Ontario, serving Mississauga, Vaughan, Oakville, Concord, Toronto, and all CSA‑regulated markets.
Available for purchase, lease‑to‑own, or fleet integration.
POWER OPTIONS (BATTERY & CHARGER)
- Battery: Not included — 36V lead‑acid and reconditioned options available
- Charger: Not included — matched 36V high‑frequency chargers available
- Freezer Options: Freezer‑rated hydraulics and cold‑storage battery packages available
- Pairing: Matched battery/charger sets based on runtime and shift pattern
Forklift Battery Chargers
Ideal Applications
- High‑bay warehousing
- Narrow‑aisle racking
- Deep‑reach pallet storage
- Distribution centers & 3PLs
- Manufacturing plants
- High‑density storage environments
Parts & Lifecycle Support
- OEM & aftermarket parts – forks, tires, controllers, tillers
- UL/EE fire-safe upgrades – available upon request
- Clamp kits – carton clamp, push/pull, slip sheet
- Freezer cab kits and cold storage battery options
- Charger pairing and diagnostics
- Tire Pressing & Installation – forklift tires, caster wheels, load wheels
- CSA/MOL inspection tagging and documentation
- Magnaflux testing for resale/export assurance
- Parts bundling with unit purchase or lease
Premier Lift Support Ecosystem
- CSA Forklift Safety Accessories & PPE
- Service & Repair
- Rentals
- Driver Training & Certification
- Book a Service
- Rental Request Form
- Watch Premier Forklifts in Action
Premier Lift Equipment supports your entire operation—not just the forklift:
- CSA/MOL Certification & Inspection
- Battery & Charger Packages – New or tested used
- Safety Accessories – Mirrors, dock chocks, decals, logbooks
- Mobile Field Service – Mississauga, Vaughan, Oakville, Toronto
- Operator Training – CSA-compliant programs Flexible Leasing & Financing (OAC)
- Trade-In Credit – Walkies, propane lifts, or legacy electrics
- Rental Bridge Programs – Keep operations running during transitions
- Magnaflux Testing – Add-on for resale/export assurance
- Full Service Shop & Paint Booth – State‑of‑the‑art refinishing, custom color matching, and full chassis rebuilds performed in‑house at our facility. Every CSA‑certified forklift can be delivered freshly painted, safety decals applied, and ready for front‑line duty.
Next Steps
- Request CSA Inspection
- Ask About Rentals
- Book Driver Training
- Trade In Your Forklift
- Watch Premier Forklifts in Action
FAQ
Is this forklift CSA certified?
Yes — fully CSA/MOL compliant.
What is the capacity?
3,000 lb.
What is the mast height?
114" lowered / 252" raised.
How many hours are on this unit?
17,934 drive / 1,885 lift.
Is a battery included?
Optional — lead‑acid or lithium packages available.
Where is it located?
Brampton, Ontario — serving the GTA and CSA export markets.
