2014 Raymond 750‑DR32TT – CSA‑Certified Deep‑Reach Forklift | 3,200 lb | 330” Triple Mast | 36V Electric | Pantograph Double‑Deep | Brampton ON
Specifications
| Manufacturer | Raymond |
| Model | 750-DR32TT |
| Year | 2014 |
| Condition | Refurbished |
| Part ID | 18221 |
| Capacity | 3200 LBS. lbs |
| Load Center | 24" |
| Raised Mast Height | 330 in |
| Lowered Mast Height | 146 in |
| Mast Type | 3 stage |
| Power Type: | 36V AC Electric |
| Voltage | 36v |
| Reach Mechanism | Pantograph – Double Deep |
| Carriage Type | Class II |
| * Fork Length | 42" |
| * Side Shifter | Yes |
| Base leg opening | 41" |
| Overall Width | 42" |
| Overall Length | 107" |
| Turning Radius | ~67" |
| Travel Speed (Loaded | ~7 mph |
| Travel Speed (Unloaded) | ~7.5 mph |
| Tilt Range | 3° forward / 6° backward |
| Hours | ~10,202 verified deadman hours |
| Tire Type | Poly cushion (indoor) |
| Weight | 8,200 lb |
| Certification | CSA/MOL Certified |
| Condition Details | Repainted, professionally refinished |
| Battery Compartment Size | 21.5" |
| Fuel Type | Electric |
| Battery Included | Optional |
| Charger Included | Optional |
| Category Overview Title | Deep‑Reach Forklifts – Double‑Deep High‑Density Storage Solutions |
| Category Overview Summary | Deep‑reach forklifts are engineered for high‑density storage environments using double‑deep racking systems. With pantograph reach mechanisms, 36V/48V electric powertrains, and lift heights up to 330”, these units maximize pallet positions while reducing aisle width requirements. CSA‑certified deep‑reach forklifts excel in 3PL, cold storage, distribution centers, and high‑bay warehouse operations where storage density and precise load placement are essential. |
Description
This CSA‑certified 2014 Raymond 750‑DR32TT is a 3,200 lb deep‑reach forklift engineered for high‑density storage and double‑deep pallet racking. With a 330" triple‑stage mast, pantograph reach mechanism, 36V AC electric powertrain, Class II carriage, and indoor poly cushion tires, it delivers precise load placement in narrow‑aisle warehouse environments. Fully reconditioned, repainted, and safety‑tagged, this unit shows approximately 10,202 verified deadman hours. Battery and charger packages are available, including freezer‑rated options for cold‑storage operations.
Refurbishment Work Completed
CSA/MOL certification
Full operational inspection
Chassis refinished with new decals
Hydraulic and electrical systems tested
Side‑shift carriage verified
42" forks installed and inspected
Freezer‑prep upgrades available
Battery and charger packages available
What’s Included
42" forks
Side‑shift carriage
CSA/MOL certification
Full inspection report
Safety decals and compliance labeling
Delivery available across Canada and the U.S.
Battery and charger available as add‑ons
This CSA‑certified 2014 Raymond 750‑DR32TT is a 3,200 lb deep‑reach forklift engineered for high‑density storage and double‑deep pallet racking. The 36V AC electric system, 330” triple‑stage mast, and pantograph reach mechanism deliver precise load handling in narrow‑aisle warehouse environments. Includes side shift, Class II carriage, and indoor poly tires. Fully reconditioned, repainted, and CSA/MOL certified for Canadian and export deployment.
Explore more CSA‑certified deep‑reach forklifts in our main category:Swing‑Mast & Deep‑Reach Forklifts – High‑Density VNA Solutions
POWER OPTIONS (BATTERY & CHARGER)
- Battery: Not included — 36V lead‑acid and reconditioned options available
- Charger: Not included — matched 36V high‑frequency chargers available
- Freezer Options: Freezer‑rated hydraulics and cold‑storage battery packages available
- Pairing: Matched battery/charger sets based on runtime and shift pattern
Ideal Applications
- Double-deep racking systems
- Grocery, pharma & 3PL pick zones
- Cold storage (freezer retrofit available)
- CSA-certified export programs
- Retrofit for aging Raymond DR or Crown RD fleets
Freezer Zone & Export Features
Optional thermal upgrade kits available:
- Insulated electronics
- Hydraulic seal enhancements
- CSA freezer-grade tuning Ideal for frozen food, beverage, and pharma distribution. Export-ready for U.S. and international markets.
Parts & Lifecycle Support
- OEM & aftermarket parts – forks, tires, controllers, tillers
- UL/EE fire-safe upgrades – available upon request
- Clamp kits – carton clamp, push/pull, slip sheet
- Freezer cab kits and cold storage battery options
- Charger pairing and diagnostics
- Tire Pressing & Installation – forklift tires, caster wheels, load wheels
- CSA/MOL inspection tagging and documentation
- Magnaflux testing for resale/export assurance
- Parts bundling with unit purchase or lease
Premier Lift Support Ecosystem
- CSA Forklift Safety Accessories & PPE
- Service & Repair
- Rentals
- Driver Training & Certification
- Book a Service
- Rental Request Form
- Watch Premier Forklifts in Action
Premier Lift Equipment supports your entire operation—not just the forklift:
- CSA/MOL Certification & Inspection
- Battery & Charger Packages – New or tested used
- Safety Accessories – Mirrors, dock chocks, decals, logbooks
- Mobile Field Service – Brampton, Mississauga, Vaughan, Oakville, Toronto
- Operator Training – CSA-compliant programs
- Flexible Leasing & Financing (OAC)
- Trade-In Credit – Walkies, propane lifts, or legacy electrics
- Rental Bridge Programs – Keep operations running during transitions
- Magnaflux Testing – Add-on for resale/export assurance
- Full Service Shop & Paint Booth – State‑of‑the‑art refinishing, custom color matching, and full chassis rebuilds performed in‑house at our facility. Every CSA‑certified forklift can be delivered freshly painted, safety decals applied, and ready for front‑line duty.
Next Steps
- Request CSA Inspection
- Ask About Rentals
- Book Driver Training
- Trade In Your Forklift
- Watch Premier Forklifts in Action
Industry Applications
Cold storage & frozen food distribution
Grocery, retail & big‑box distribution centers
3PL warehousing & cross‑dock logistics
Pharmaceutical & medical distribution
Beverage & alcohol distribution
Manufacturing & light industrial operations
Aerospace & precision parts handling
Clean‑energy & renewables facilities
Data centers & critical‑infrastructure environments
Recycling & waste‑management operations
Frequently Asked Questions – Raymond 750-DR32TT
Does this unit include a battery?
No — sold chassis‑only. Battery and charger available separately.
Is this forklift CSA/MOL certified?
Yes — fully certified with documentation and safety tagging.
Can this unit operate in freezer zones?
Yes — compatible with heater kits and freezer‑rated battery upgrades.
Is this a good fit for double‑deep racking?
Yes — the pantograph reach system and 330” lift height are ideal for high‑density storage.
Do you offer trade‑in credit?
Yes — trade‑in programs available for Raymond, Crown, and other electric fleets.
Do you offer Magnaflux testing?
Yes — available for resale and export assurance.
What about cosmetic condition?
Every forklift can be delivered freshly painted with safety decals applied.
