24 Volt 925 Amp Hour | Ametek Prestolite 786513‑18UM | Industrial Forklift Battery Charger | 228A Max Output | 208/480/575V 3‑Phase | CSA‑Certified
Specifications
| Manufacturer | Ametek Prestolite Power |
| Model | 786513‑18UM |
| Condition | Used |
| Serial Number | 10GSG77701 |
| Stock Number | 5951544 |
| Part Number | 5006G771‑003 |
| Voltage Output (V) | 24V |
| Amperage Output (A) | Up to 228A |
| Battery Compatibility | Lead‑Acid (LA), 12 Cells |
| Rated 8‑Hour Capacity | 925 Ahr |
| Supported Manufacturers | Toyota • Raymond • Crown • Hyster • Yale • Cat • Mitsubishi • UniCarriers • Clark • Komatsu • Hyundai • Hangcha • BYD • Linde • STILL • Doosan • Bendi • Combilift • Drexel |
| Charging Type | Conventional |
| Input Power Requirements | 3‑Phase |
| Input Voltage (AC Supply) | 208 / 480 / 575V |
| Input Amperage | 35 / 21 / 16 / 14.7A |
| Connector Type | SB (confirm model if needed) |
| BMS Communication | No (Lead‑Acid) |
| Charge Curve / Profile | IUla |
| Cooling Type | Fan‑Cooled |
| Mounting Type | Floor‑Mount |
| Included Accessories | Standard AC cord & DC leads |
| Display & Diagnostics | LED indicators |
| Certification | CSA Certified |
| Warranty | Coverage varies by region |
| Available Conditions | Used • Load‑Tested • Fully Inspected |
| Frequency | 60 Hz |
| Category Overview Title | 24V Forklift Battery Charger | 228A Max | CSA‑Certified | Ametek Prestolite 786513‑18UM |
| Category Overview Summary | Industrial 24V forklift battery charger with up to 228A output for 12‑cell lead‑acid batteries. CSA‑certified, 208/480/575V 3‑phase input, fully inspected and load‑tested for warehouse, manufacturing, and distribution fleets. |
Description
The Ametek Prestolite 786513‑18UM is a heavy‑duty 24V industrial forklift battery charger designed for high‑capacity 12‑cell lead‑acid batteries. With a maximum output of 228A and a rated 8‑hour capacity of 925 Ahr, this unit is suitable for pallet trucks, walkies, and mid‑voltage equipment operating in demanding warehouse and distribution environments.
This charger supports 208V, 480V, and 575V 3‑phase input power, making it compatible with a wide range of facility electrical systems. Each unit is fully inspected, load‑tested, and integration‑verified to ensure safe operation with your fleet and power infrastructure.
BATTERY & CHARGER OPTIONS (UNIVERSAL 24V + 36V + 48V BLOCK)
Premier Lift supplies 24V, 36V, and 48V industrial batteries and smart chargers for electric forklifts, pallet trucks, walkies, and sit‑down electrics. Options include reconditioned lead‑acid packs, AGM sealed batteries, and lithium‑ion retrofit kits.
Available Add‑Ons
• 24V, 36V, or 48V reconditioned industrial batteries
• AGM sealed maintenance‑free batteries
• Lithium‑ion retrofit packages
• Single‑phase or three‑phase smart chargers
• Freezer‑rated battery heaters and insulation kits
• Battery watering systems
• Charger wall‑mount kits
• Opportunity‑charge compatible options
Why Add a Battery & Charger Package
• Ensures compatibility with major OEMs
• Improves runtime and charge efficiency
• Supports CSA/MOL compliance
• Export‑ready documentation available
For buyers comparing multiple charging solutions, this unit is part of our forklift battery charger lineup, which includes single‑phase, three‑phase, high‑frequency, and multi‑voltage industrial chargers. This helps ensure proper matching between charger output, battery voltage, and Ahr capacity across 24V, 36V, 48V, and 80V electric forklift systems.
Related Category:
Disclaimer
All specifications are believed accurate but may vary by prior configuration or modification. Buyers must verify all critical details before purchase.
