2018 Raymond 730‑DR30TT – CSA‑Certified Deep‑Reach Forklift | 3,000 lb | 201” Triple Mast | 36V Electric | Pantograph Double‑Deep | Brampton ON
Specifications
| Manufacturer | Raymond |
| Model | 730-DR30TT |
| Year | 2018 |
| Condition | Refurbished |
| Part ID | 18083 |
| Capacity | 3000 LBS. lbs |
| Load Center | 24" |
| Raised Mast Height | 201 in |
| Lowered Mast Height | 90 in |
| Mast Type | 3 stage |
| Power Type | Electric |
| Reach Mechanism | Deep reach – Pantograph arm |
| Carriage Type | CLASS II - 16" |
| * Fork Length | 42" |
| Overall Width | 41" |
| Overall Length | 108" |
| Turning Radius | Narrow‑aisle optimized |
| Travel Speed (Loaded) | Standard Raymond spec |
| Travel Speed (Unloaded) | Standard Raymond spec |
| Tilt Range | Standard reach‑truck tilt |
| Hours | ~3,200 verified deadman hours |
| Tire Type | Indoor poly cushion |
| Weight (Truck Weight) | Standard Raymond DR weight (battery‑excluded) |
| Certification | CSA/MOL Certified |
| Condition Details | Reconditioned, repainted, safety‑tagged |
| Battery Compartment Size | Standard Raymond DR compartment |
| Fuel Type | Electric |
| Battery Included | Optional |
| Charger Included | Optional |
| Category Overview Title | Deep‑Reach Forklifts – Double‑Deep High‑Density Storage Solutions |
| Category Overview Summary | Deep‑reach forklifts are engineered for high‑density storage environments using double‑deep racking systems. With pantograph reach mechanisms, 36V/48V electric powertrains, and lift heights up to 330”, these units maximize pallet positions while reducing aisle width requirements. CSA‑certified deep‑reach forklifts excel in 3PL, cold storage, distribution centers, and high‑bay warehouse operations where storage density and precise load placement are essential. |
Description
This CSA certified 2018 Raymond 730 DR30TT is a reconditioned 3,000 lb deep reach forklift built for high density double deep racking and narrow aisle warehouse operations. Its 201 inch triple stage mast, 36V AC electric system, and pantograph reach mechanism provide precise load placement for grocery, 3PL, pharma, and cold storage environments. Fully refinished and CSA MOL certified, this unit is ready for compliant deployment across Canada and the United States.
REFURBISHMENT WORK COMPLETED
CSA MOL certification with safety tagging and documentation
Full repaint and refinishing
Pantograph reach mechanism inspected and load tested
201 inch triple stage mast, chains, and hydraulics verified
Electrical system tested for 36V AC performance
Indoor poly tires inspected and serviced
Battery compartment cleaned and prepped for 36V packs
Freezer zone retrofit options available
WHATS INCLUDED
201 inch triple stage mast
Pantograph double deep reach mechanism
Side shift with Class II carriage
42 inch forks
CSA MOL certification package
Fresh paint and safety decals
Delivery across Canada and the United States
Optional 36V battery and matched high frequency charger packages
POWER OPTIONS (BATTERY & CHARGER)
- Battery: Not included — 36V lead‑acid and reconditioned options available
- Charger: Not included — matched 36V high‑frequency chargers available
- Freezer Options: Freezer‑rated hydraulics and cold‑storage battery packages available
- Pairing: Matched battery/charger sets based on runtime and shift pattern
Forklift Battery Chargers
Ideal Applications
- Cooler zones and refrigerated pick modules
- Grocery, pharma & 3PL fulfillment
- CSA-certified export programs
- Retrofit for aging Raymond DR or Crown RD fleets
- Narrow aisle double-deep racking layouts
Cold Storage Prep Available
Optional upgrade includes freezer-rated seals, low-temp battery insulation, and CSA freezer zone compliance. Ideal for perishable logistics, beverage distribution, and pharma-grade warehousing.
Parts & Lifecycle Support
- CSA/MOL inspection tagging – decals, brake tags, logbooks
- LED lighting kits, comfort mats, backup alarms
- Charger diagnostics & pairing – matched kits available
- Freezer-rated battery bundles – available for cold storage
- Magnaflux testing – resale/export assurance
- Export documentation & freight prep
Premier Lift Support Ecosystem
- CSA Forklift Safety Accessories & PPE
- Service & Repair
- Rentals
- Driver Training & Certification
- Book a Service
- Rental Request Form
- Watch Premier Forklifts in Action
Premier Lift Equipment supports your entire operation—not just the forklift:
- CSA/MOL Certification & Inspection
- Battery & Charger Packages – New or tested used
- Safety Accessories – Mirrors, dock chocks, decals, logbooks
- Mobile Field Service – Brampton, Mississauga, Vaughan, Oakville, Toronto
- Operator Training – CSA-compliant programs
- Flexible Leasing & Financing (OAC)
- Trade-In Credit – Walkies, propane lifts, or legacy electrics
- Rental Bridge Programs – Keep operations running during transitions
- Magnaflux Testing – Add-on for resale/export assurance
- Full Service Shop & Paint Booth – State‑of‑the‑art refinishing, custom color matching, and full chassis rebuilds performed in‑house at our facility. Every CSA‑certified forklift can be delivered freshly painted, safety decals applied, and ready for front‑line duty.
Next Steps
- Request CSA Inspection
- Ask About Rentals
- Book Driver Training
- Trade In Your Forklift
- Watch Premier Forklifts in Action
Industry Applications
Cold storage & frozen food distribution
Grocery, retail & big‑box distribution centers
3PL warehousing & cross‑dock logistics
Pharmaceutical & medical distribution
Beverage & alcohol distribution
Manufacturing & light industrial operations
Aerospace & precision parts handling
Clean‑energy & renewables facilities
Data centers & critical‑infrastructure environments
Recycling & waste‑management operations
Frequently Asked Questions – Raymond 730-DR30TT(Stock #18083)
Is this unit freezer‑compatible?
Yes — freezer‑rated upgrades available.
Does it include a battery?
No — battery and charger are optional.
Is it CSA certified?
Yes — fully CSA/MOL inspected and tagged.
Is it suitable for double‑deep racking?
Yes — pantograph reach and 201" lift are ideal for high‑density storage.
Do you accept trade‑ins?
Yes — propane, walkies, and electrics accepted.
Is Magnaflux testing available?
Yes — recommended for export assurance.
Related Insights & Buyer Tools
- The Forklift Paradox: Safer, Smarter Warehouses Ahead
- Racking or Forklifts First? The Real Answer
- CSA-Certified Used Forklifts vs. Cheap Imports
- Forklift Rentals | Electric & Propane Units | Premier Lift GTA
- Forklift Safety Checklists: Compliance & Prevention
- Sustainable Forklift Practices That Save You Money
- Building Trust Through Honest Forklift Reviews
- CSA-Certified Propane and Electric Forklifts | Premier Lift
- Chassis-Only Forklift Pricing | Premier Lift Equipment
More CSA Insights & Buyer Strategy
- Premier Lift | Originators of Semantic Forklift Protocol
- Why Buyers Search “CSA Forklifts Near Me” | Premier Lift
Watch Premier Forklifts in Action
Let’s Get You Moving with Confidence
This Raymond 730-DR30TT is CSA-certified, freezer-compatible, and built to lift to 16.75 ft with precision. Whether you're upgrading your fleet or outfitting a new double-deep racking zone, you’ve found the right unit—and the right team.
Email: sales@premierliftequipment.com
Call: 905‑452‑8361
Website: PremierLiftEquipment.com
Who We Are – Premier Lift Equipment
From shop floor straight to your door—forklifts made simple. Premier Lift Equipment is Canada’s most trusted forklift partner, delivering CSA-certified inventory, expert service, and full-spectrum support across Ontario, the U.S., and the Caribbean.
Watch our story on YouTube
Sales • Rentals • Service • Certification • Accessories • Export Logistics
Outfit your fleet with safety gear: CSA Forklift Safety Accessories & PPE | Premier Lift Brampton ON
Ask about flexible financing: Why Trade In Your Forklift Instead of Scrapping It?
Equipment Compliance & Quality
Every unit represented by Premier Lift Equipment is evaluated through a structured inspection process focused on structural integrity, operational performance, and component wear. Equipment is prepared in alignment with CSA/MOL safety expectations, OEM‑recommended inspection standards, and the operational requirements of warehousing, manufacturing, 3PL, cold storage, and broader industrial environments.
Our intake and reconditioning workflow verifies specifications, features, and performance details for accuracy. Supporting documentation — including service records, battery health reports, and certification history — is available upon request to assist with compliance, audit readiness, and operational planning.
Specifications are believed accurate but not guaranteed. Variations may occur based on configuration or prior modifications. Buyers are responsible for verifying all critical details before purchase. Need a delivered price or compliance package? Request a delivered quote for fast turnaround across Canada.
